AMI BEARINGS
Call
AMI BEARINGS MUCFBL201B
#MUCFBL201B
On request
Flange-Mount Ball Bearing Unit - Three-Bolt Bracket Style, 12 mm Bore, PBT Thermoplastic Housing, Standard Duty, Set Screw Locking, Contact with Flinger
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | AMI BEARINGS |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 12 mm |
| Vertical bolt spacing | 22.2 mm |
| Bore type | Round |
| Shaft centerline height | 42.9 mm |
| Duty type | Standard Duty |
| Hub diameter | 63.5 mm |
| Mounting type | Three-Bolt Bracket Style |
| Bracket width | 62 mm |
| Housing material | PBT Thermoplastic |
| Unit standoff | 33.7 mm |
| Locking device | Set Screw |
| Bolt size | M10 |
| Radial dynamic load capacity | 1110 kgf |
| Lubrication type | Lubrication Fitting |
| Radial static load capacity | 540 kgf |
| Series | MUCFBL200B |
| Seal type | Contact with Flinger |
| Replacement bearing | MUC201 |
| Length through bore | 31 mm |
| Manufacturer product page | http://catalog.amibearings.com/item/three-bolt-flange-units-2/ng-three-bolt-flange-bracket-unit-mucfbl200-series/mucfbl201b |
| Horizontal bolt spacing | 38.1 mm |
