AMI BEARINGS MUFL005
#MUFL005
On request
Flange-Mount Ball Bearing Unit - Two-Bolt Flange, 25 mm Bore, ZDC Alloy with Electroless Chromate Finish Housing, Light Duty, Eccentric Collar Locking, Contact Seal
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | AMI BEARINGS |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 25 mm |
| Radial dynamic load capacity | 2150 lbf |
| Bolt center-to-center length | 75 mm |
| Radial static load capacity | 1080 lbf |
| Overall length/diameter | 95 mm |
| Seal type | Contact Seal |
| Bore type | Round |
| Length through bore | 0.866 in |
| Duty type | Light Duty |
| Lubrication type | Cannot Be Relubricated |
| Mounting type | Two-Bolt Flange |
| Series | MUFL000 |
| Housing material | ZDC Alloy with Electroless Chromate Finish |
| Replacement bearing | MU005 |
| Locking device | Eccentric Collar |
