AMI BEARINGS MUCFPL205CEB
#MUCFPL205CEB
On request
Flange-Mount Ball Bearing Unit - Four-Bolt Flange, 25 mm Bore, PBT Thermoplastic Housing, Standard Duty, Set Screw Locking, Contact with Flinger
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | AMI BEARINGS |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 25 mm |
| Radial dynamic load capacity | 1220 kgf |
| Bolt center-to-center length | 70 mm |
| Radial static load capacity | 640 kgf |
| Bore type | Round |
| Seal type | Contact with Flinger |
| Duty type | Standard Duty |
| End type | 1 Closed Cover |
| Mounting type | Four-Bolt Flange |
| Length through bore | 34 mm |
| Housing material | PBT Thermoplastic |
| Lubrication type | Lubrication Fitting |
| Locking device | Set Screw |
| Series | MUCFPL200CEB |
| Expansion type | Non-Expansion Bearing (Fixed) |
| Replacement bearing | MUC205 |
