BROWNING
Call
BROWNING 2525X2
#2525X2
On request
3749975
Manufacturer description3749975 Taper Bore Bushing - 2525 Series, 2.0000 in Bore, 3.3750 in OD, 2.5000 in LTB
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
BROWNING — BROWNING 2525X2
- Mounts flush in products - No protruding flanges to interfere with the drive
- Key to Key Drive - Capscrews act as an external key
- 1 1/2"/ft. Taper on Barrel - Since this is a non-self locking taper it provides ease of installation and removal of products from the shaft.
Specifications
| Brand | BROWNING |
| Category | TAPER LOCKING BUSHINGS |
| Bore diameter | 2 in |
| Screw torque | 430 in-lbs |
| Outside diameter | 3.375 in |
| Barrel diameter | 3.25 in |
| Length through bore | 2.5 in |
| Screw length | 1 in |
| Bushing size | 2525 |
| Manufacturer catalog number | 3749975 |
| Bore type | Finished w/ Keyway |
| Manufacturer upc number | 662289617135 |
| Keyway size | 1/2 x 1/4 in |
| Weight | 3.16 lbs |
| Torque capacity | 11300 in-lbs |
