BROWNING 60H200SF
#60H200SF
On request
3514221
Manufacturer description3514221 Synchronous Gearbelt Sprocket - 0.5000 in Pitch, 60 Tooth, 9.4950 in OD, 2.0000 in Belt Width
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
BROWNING — BROWNING 60H200SF
- Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets
- Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor
- Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement
- Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper & QD Bushing styles, as well as, finished and minimum plain bore
Specifications
| Brand | BROWNING |
| Category | TIMING BELT PULLEYS |
| Number of teeth | 60 |
| Material | Cast Iron |
| Belt width | 2 in |
| Length through bore | 2 in |
| Pitch | 1/2 in |
| Face width | 2.3438 in |
| Pitch diameter | 9.549 in |
| Pulley construction | Plain |
| Belt type | H |
| Number of hubs | 1 |
| Bore type | QD Bushed |
| Manufacturer catalog number | 3514221 |
| Bushing series | SF |
| Manufacturer upc number | 662289353187 |
| With flanges | No Flanges |
| Cad drawing | https://www.3dcontentcentral.com/PremiumSSS-Download-Model.aspx?catalogId=12261&id=18636 |
| Bushing bore range | 0.5000 to 2.9375 in |
| Weight | 17.52 lbs |
| Outside diameter | 9.495 in |
