On request
BROWNING
Call
BROWNING 40H300SK
#40H300SK
On request
3514353
Manufacturer description3514353 Gearbelt Sprocket - 0.5000 in Pitch, 40 Tooth, 0.5000 to 2.6250 in Bore Dia., 6.3120 in OD, 3.0000 in Belt Width
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
BROWNING — BROWNING 40H300SK
- Constant Speed - No slip; no creep; minimum backlash due to the positive engagement of the belt teeth with the grooves of the sprockets
- Light Weight - High horsepower-to-weight ratio makes Browning Gearbelt drives ideal for any application where weight is a factor
- Broad depth of product to choose from - Browning offers 5 different sprocket pitches along with a wide range of sprocket and belt widths to accommodate any horsepower requirement
- Different Mounting to the shaft - Browning offers the Gearbelt Pulleys in various ways to mount to the shaft; Split Taper & QD Bushing styles, as well as, finished and minimum plain bore.
Specifications
| Brand | BROWNING |
| Category | TIMING BELT PULLEYS |
| Number of teeth | 40 |
| Belt type | H |
| Belt width | 3 in |
| Outside diameter | 6.312 in |
| Pitch | 0.5 in |
| Face width | 3.375 in |
| Bore diameter | 0.5000 to 2.6250 in |
| Manufacturer catalog number | 3514353 |
| Flange outside diameter | 6.5625 in |
| Manufacturer upc number | 662289351480 |
| Pitch diameter | 6.366 in |
