BROWNING 63V800SK

Name: BROWNING 63V800SK
Brand: BROWNING
SKU: 63V800SK

#63V800SK On request

Brand BROWNING

Category V-BELT PULLEYS

Part Number 63V800SK

1065275

Manufacturer description

1065275 Bushing Bore V-Belt Pulley - 3V Belt Section, 6 Groove, 7.95 in Pitch Dia., 8.00 in O.D., QD Bushed, SK Series Bushing, Cast Iron Material

Price on request — a consultant will confirm lead time and terms.

Talk to a technical consultant

Specifications

Brand	BROWNING
Category	V-BELT PULLEYS
Number of grooves	6
Keyway size	1/2 x 1/4 (1-13/16 to 2-1/4 Bore) , 1/4 x 1/8 (15/16 to 1-1/4 Bore) , 1/8 x 1/16 (1/2 to 9/16 Bore) , 3/16 x 3/32 (5/8 to 7/8 Bore) , 3/8 x 3/16 (1-7/16 to 1-3/4 Bore) , 5/16 x 5/32 (1-5/16 to 1-3/8 Bore) , 5/8 x 5/16 (2-5/16 to 2-3/4 Bore) in
Outside diameter	8 in
Material	Cast Iron
Length through bore	1.9375 in
Bushing bore range	1/2 to 2-5/8 in
Face width	2.7188 in
Pitch diameter	7.95 in
Belt section size	3V
Overall width	2-23/32 in
Bore type	QD Bushed
Pulley construction	Webbed
Bushing series	SK
Cad drawing	https://www.3dcontentcentral.com/PremiumSSS-Download-Model.aspx?catalogId=12261&id=18716
