On request
DODGE
Call
DODGE PX4
#PX4
On request
119987
Manufacturer description119987 Quick Disconnect Bushing - P Bushing, 4.0000 in Bore, 11.7500 in Flg OD, 9.3800 in LTB, Material: Steel
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
DODGE — DODGE PX4
- Flanged
- 4° taper
- Easy on, easy off
- Manufactured precisely to industry standards
- Conventional or reverse mounting
Specifications
| Brand | DODGE |
| Category | QD BUSHINGS |
| Bore diameter | 4 in |
| Screw torque | 5400 in-lbs |
| Flange outside diameter | 11.75 in |
| Barrel diameter | 8.25 in |
| Flange thickness | 1.75 in |
| Barrel length | 7.25 in |
| Length through bore | 9.38 in |
| Bolt circle diameter | 10 in |
| Bushing size | P |
| Number of bolt holes | 4 |
| Bore type | Finished w/ Keyway |
| Screw thread size | 1-8 |
| Keyway size | 1 x 1/2 in |
| Screw length | 9-1/2 in |
| Material | Steel |
| Manufacturer catalog number | 119987 |
| Torque capacity | 250000 in-lbs |
| Includes | Std Bolts |
| Mounting type | Conventional or Reverse |
| Manufacturer upc number | 782476315658 |
