DODGE
Call
DODGE P4BTFXT700RE
#P4BTFXT700RE
On request
23609
Manufacturer descriptionPillow Block Roller Bearing Unit - 7.0000 in Bore Dia., Four-Bolt Base, Split Pillow Block, Cast Iron Material, Expansion Bearing (Floating)
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | DODGE |
| Category | PILLOW BLOCK ROLLER BEARING UNITS |
| Bore diameter | 7 in |
| Base width | 7-1/2 in |
| Overall length | 28 in |
| Expansion type | Expansion Bearing (Floating) |
| Overall height | 16.5625 in |
| Finish/coating | Black Oxide |
| Mounting | Four-Bolt Base |
| Overall width | 10-1/2 in |
| Bearing type | Tapered Roller |
| Seal type | Triple Lip |
| Bore type | Round |
| Radial dynamic load capacity | 69200 lb |
| Housing construction | Split Pillow Block |
| Radial static load capacity | 574000 lb |
| Base to bore centerline | 7.875 in |
| Maximum rpm | 790 RPM |
| Duty type | Standard Duty |
| Lubrication type | Lubrication Fitting |
| Housing material | Cast Iron |
| Series | 538 |
| Locking device | Concentric Collar |
| Standards met | UL, AFBMA, AGMA, ASMMA, ASTM A48 Class 30, BSA, CMA, MPTA, PTDA |
| Bolt center-to-center length | 21.63 to 24.38 in |
| Manufacturer catalog number | 23609 |
