On request
FAG (SCHAEFFLER)
Call
FAG (SCHAEFFLER) NU2230-E-M1-C3
#NU2230-E-M1-C3
On request
NU2230-E-XL-M1-C3
Manufacturer descriptionCylindrical Roller Bearing - Straight, 150 mm ID, 270 mm OD, 73 mm Width, C3 Internal Clearance
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | FAG (SCHAEFFLER) |
| Category | CYLINDRICAL ROLLER BEARINGS |
| Bore diameter | 150 mm |
| Static load capacity | 970000 N |
| Outside diameter | 270 mm |
| Precision rating | Not Rated |
| Overall width | 73 mm |
| Maximum rpm | 3950 RPM |
| Flanges | (2) Outer Ring |
| Cage material | Brass |
| Bore type | Straight |
| Finish/coating | Uncoated |
| Number of rows | 1 |
| Closure type | Open |
| Internal clearance | C3 |
| Outer ring width | 73 mm |
| Ring separation | Separable Outer Ring |
| Fillet radius | 2.5 mm |
| Operating temperature range | -30 to +150 °C |
| Series | NU22 |
| Dynamic load capacity | 780000 N |
