LEESON ELECTRIC GT1310A
#GT1310A
On request
182TTFBD6029
Manufacturer description182TTFBD6029 General Purpose Motor - 3 ph, 3 hp, 1800 rpm, 230/460 V, 182TC Frame, TEFC (Totally Enclosed Fan Cooled) Enclosure, 60 Hz, Round Mount, 1762 rpm Base RPM
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
LEESON ELECTRIC — LEESON ELECTRIC GT1310A
- Meets or exceeds NEMA Premium® efficiency. Model is in compliance with EISA2007
- Hazardous Duty Division 2, Zone 2, Class I, Groups A,B,C,D, Temperature code T2B
- IP55 enclosure on cast iron frames
- Inverter Duty 10:1 Variable and up to 10:1 Constant Torque
- Class F Insulation
Specifications
| Brand | LEESON ELECTRIC |
| Category | GENERAL PURPOSE MOTORS |
| Motor phase | 3 ph |
| Shaft type | T |
| Motor horsepower | 3 hp |
| Motor length less shaft | 5.85 in |
| Synchronous rpm | 1800 rpm |
| Ambient temperature range | 40 °C |
| Motor supply voltage | 230/460 V |
| Bearing type | Ball Bearing |
| Frame size | 182TC |
| Opposite drive end bearing type | Ball |
| Enclosure type | TEFC (Totally Enclosed Fan Cooled) |
| Service factor | 1.15 |
| Frequency rating | 60 Hz |
| Frame material | Rolled Steel |
| Mounting type | Round |
| Insulation class | F |
| Base rpm | 1762 rpm |
| Ip rating | 43 |
| Assembly/box mounting | F1/F2 CAPABLE |
| Standards met | CE,UL Recognized,CSA |
| Duty / condition type | Continuous Duty |
| Motor design code | B |
| Full load current | 8.00 / 4.00 A |
| Drive end bearing size | 6206 |
| Electrical type | Squirrel Cage Inverter Rated |
| Opposite drive end bearing size | 6205 |
| Full load efficiency | 0.895 |
| Overload protector | No Overload Protector |
| Kva code | K |
| Weight | 87 lbs |
| Kw | 2.2 kW |
| Manufacturer upc number | 722856063724 |
| Motor orientation | Horizontal |
| Motor poles | 4 |
| Storage dimension height | 14.48 in |
| Number of speeds | 1 |
| Storage dimension width | 16.53 in |
| Starting method | Line Or Inverter |
| Storage dimension length | 18.42 in |
| Shaft diameter | 1.125 in |
| Shaft rotation | Reversible |
