MARTIN SPROCKET & GEAR D12C76
#D12C76
On request
Stock Bore Sprocket - Metric - 12B / 3/4 in, C Hub, 76 Teeth, 40 mm Stock Bore, Steel Material
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
MARTIN SPROCKET & GEAR — MARTIN SPROCKET & GEAR D12C76
- Martin metric double strand solid construction sprockets have proper spacing between chain rows.
- The sprockets are manufactured from high carbon steel.
- Martin does not stack “A” plates on multiples, but instead Martin machines teeth after the chain rows are already in place.
- These plain bore sprockets can easily be bored to a metric or standard size to fit your application.
- Keyways, set screws and harden teeth are quick alterations that can be made.
Specifications
| Brand | MARTIN SPROCKET & GEAR |
| Category | STOCK BORE SPROCKETS |
| Chain number & pitch | 12B / 3/4 in |
| Pitch diameter | 461 mm |
| Chain / sprocket type | Metric Roller Chain |
| Maximum bore diameter | 90 mm |
| Hub outside diameter | 130 mm |
| Tooth width | 30 mm |
| Hub style | C |
| Tooth thickness | 11 mm |
| Number of teeth | 76 |
| Width across tooth sets | 30.33 mm |
| Bore type | Reboreable |
| Chain roller diameter | 12.065 mm |
| Bore diameter | 40 mm |
| Chain roller width | 11.68 mm |
| Number of strands across | 2 |
| Storage dimension height | 2.95 mm |
| Material | Steel |
| Storage dimension length | 18.61 mm |
| Number of hubs | 2 |
| Storage dimension width | 18.61 mm |
| Length through bore | 75 mm |
| Surface treatment | Protective Coating |
| Hardened teeth | Non-Hardened Teeth |
| Manufacturer upc number | 697950401614 |
| Pitch type | Single |
| Outside diameter | 472.7 mm |
| Weight | 62.75 lbs |
| Caliper diameter | 448.9 mm |
