MORSE 600Q210H30

Name: MORSE 600Q210H30
Brand: MORSE
SKU: 600Q210H30

#600Q210H30 On request

Brand MORSE

Category RIGHT ANGLE WORM GEAR SPEED REDUCERS

Part Number 600Q210H30

XM0237

Manufacturer description

XM0237 Right Angle Worm Gear Speed Reducer - Single Reduction, 30:1 Ratio, 6.00 in Center Distance, C-Face Quill, 1.3750 in Input Size, Double Output Output, 213/215T Frame

Price on request — a consultant will confirm lead time and terms.

Need to confirm compatibility?

Talk to a technical consultant

Call

MORSE — MORSE 600Q210H30

Rugged Cast-Iron Housing: Provides maximum strength and dependability
Integral Worm and Shaft: Carburized and hardened to 58RC for extra strength
Tapered Roller Bearings On Input and Output Shafts: Absorb radial and thrust loads
Cast Bronze Worm Gears: Provide optimum balance of strength and wear resistance

Specifications

Brand	MORSE
Category	RIGHT ANGLE WORM GEAR SPEED REDUCERS
Reduction	Single
Seal material	Nitrile
Center distance	6 in
Overhung load capacity	4417 lb
Maximum input horsepower	10.260 @ 1750 rpm_x000D_ hp
Standard base kit	XM9000
Vertical low base kit	XD9002
Output direction	Double Output
Vertical high base kit	XD9003
Manufacturer reducer size	600
Vertical j base kit	XM9003
Input type	C-Face Quill
Hollow output flange kit	XD9001
Input size	1.375 in
Bushing kit	315BU
Output type	Solid Shaft
Fan cooling kit	XM9006
Output size	3.9375 in
Torque arm kit	XD9005
Nema / iec frame size	213/215T
Maximum output torque	58.3 in-lbs @1750 rpm input
Cad drawing	https://www.3dcontentcentral.com/PremiumSSS-Download-Model.aspx?catalogId=12261&id=4541
Housing material	Cast Iron
Manufacturer upc number	662000000000
