On request
MRC (SKF)
Call
MRC (SKF) 1205E
#1205E
On request
Self-Aligning Ball Bearing - Straight Bore, 25 mm ID, 52 mm OD, 15 mm Width, Open, C0
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
MRC (SKF) — MRC (SKF) 1205E
- Self-aligning bearings have two rows of balls with a common sphered raceway in the outer ring
- This gives the bearings their self-aligning property, permitting angular misalignment of the shaft relative to the housing
Specifications
| Brand | MRC (SKF) |
| Category | SELF-ALIGNING BALL BEARINGS |
| Bore diameter | 25 mm |
| Precision rating | ABEC 1 (ISO Class Normal) |
| Outside diameter | 52 mm |
| Maximum rpm | 16000 RPM |
| Overall width | 15 mm |
| Cage material | Nylon |
| Bore type | Straight |
| Finish/coating | Uncoated |
| Closure type | Open |
| Maximum misalignment | 2.5 ° |
| Internal clearance | C0 |
| Outer ring width | 15 mm |
| Dynamic load capacity | 3220 lbf |
| Fillet radius | 1 mm |
| Static load capacity | 899 lbf |
| Series | 1200 |
