On request
NTN
Call
NTN 30302
#30302
On request
Tapered Roller Bearing Set - 0.5906 in Bore, 1.6535 in OD, 13 mm Cone Width, 11 mm Cup Width, Class 0 Precision Rating
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | NTN |
| Category | TAPERED ROLLER BEARING FULL ASSEMBLIES |
| Bore diameter | 0.5906 in |
| Operating temperature range | -40 to 250 °F |
| Cup width | 11 mm |
| Dynamic load capacity | 5200 lbf |
| Assembly type | Cone & Cup |
| Fillet radius | 1 mm |
| Outside diameter | 1.6535 in |
| Static load capacity | 4700 lbf |
| Cone width | 13 mm |
| Manufacturer product page | http://bearingfinder.ntnamericas.com/item/metric-iso-series-tapered-roller-bearings/tapered-roller-set---metric-series/30302/?plpver=1009 |
| Closure type | Open |
| Cad drawing | https://bearingfinder.ntnamericas.com/cadviewer/ThreeDim?sn=30303&plpVer=1009 |
| Overall width | 0.561 in |
| Manufacturer upc number | 4547359003253 |
| Abma precision rating | Class 0 |
| Harmonization code | 8482.20.0040 |
| Bearing material | Case Carburized Steel |
| Weight | 0.295 lbs |
