NTN 607ZZ
#607ZZ
On request
Radial/Deep Groove Ball Bearing - Round Bore, 7 mm ID, 19 mm OD, 6 mm Width, Double Shielded, Internal Clearance: CN
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | NTN |
| Category | RADIAL & DEEP GROOVE BALL BEARINGS |
| Bore diameter | 7 mm |
| Precision rating | ISO Class 0 |
| Outside diameter | 19 mm |
| Finish/coating | Uncoated |
| Overall width | 6 mm |
| Bearing material | High Carbon Chrome Steel |
| Bore type | Round |
| Cage material | Steel |
| Closure type | Double Shielded |
| Inner ring width | 6 mm |
| Row type & fill slot | Single Row Non-Fill Slot |
| Outer ring width | 6 mm |
| Snap ring included | Without Snap Ring |
| Maximum rpm (grease) | 34000 rpm |
| Internal clearance | CN |
| Fillet radius | 0.3 mm |
| Operating temperature range | -40 to 120 ºC |
| Maximum rpm | 40000 RPM |
| Dynamic load capacity | 2240 N |
| Series | Micro |
| Static load capacity | 910 N |
| Manufacturer product page | http://bearingfinder.ntnamericas.com/item/deep-groove-ball-bearings/single-row-radial-ball-bearings/607zz/?plpver=1009 |
Related products
Illustrative image
