NTN 29344E
#29344E
On request
Spherical Roller Thrust Bearing - 220 mm Bore, 360 mm OD, 85 mm Width, Through Hardened Steel Material
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | NTN |
| Category | SPHERICAL ROLLER THRUST BEARINGS |
| Bore diameter | 220 mm |
| Bearing material | Through Hardened Steel |
| Outside diameter | 360 mm |
| Operating temperature range | -40 to 200 ºC |
| Overall width | 85 mm |
| Maximum rpm | 980 rpm |
| Cage type | Pressed |
| Separable type | Separable Bearing |
| Enclosure | Open |
| Fillet radius | 4 mm |
| Cage material | Brass |
| Series | 293 |
| Static load capacity | 6300000 N |
| Manufacturer product page | http://bearingfinder.ntnamericas.com/item/spherical-roller-bearings/spherical-roller-thrust-bearings/29344e/?plpver=1009 |
| Dynamic load capacity | 1740000 N |
