NTN 2212
#2212
On request
Self-Aligning Ball Bearing - Straight Bore, 60 mm ID, 110 mm OD, 28 mm Width, Open, CN
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | NTN |
| Category | SELF-ALIGNING BALL BEARINGS |
| Bore diameter | 60 mm |
| Precision rating | Class 0 |
| Outside diameter | 110 mm |
| Maximum rpm | 6300 rpm |
| Overall width | 28 mm |
| Bearing material | High Carbon Chrome Steel |
| Bore type | Straight |
| Cage material | Steel |
| Closure type | Open |
| Finish/coating | Uncoated |
| Internal clearance | CN |
| Outer ring width | 28 mm |
| Operating temperature range | -40 to 120 ºC |
| Fillet radius | 1.5 mm |
| Dynamic load capacity | 34000 N |
| Manufacturer product page | http://bearingfinder.ntnamericas.com/item/ball-bearings/self-aligning-ball-bearings/2212/?plpver=1009 |
| Static load capacity | 12600 N |
