On request
SEALMASTER
Call
SEALMASTER SFT-20RT
#SFT-20RT
On request
714718
Manufacturer description714718 Flange-Mount Ball Bearing Unit - Two-Bolt Flange, 1.2500 in Bore, Cast Iron Housing, Standard Duty, Skwezloc Collar Locking, Felt Seal
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
SEALMASTER — SEALMASTER SFT-20RT
- With Seal Flinger
- GoldPlex-HP Grease
Specifications
| Brand | SEALMASTER |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 1.25 in |
| Bearing material | 52100 Steel/Black Oxide |
| Bolt center-to-center length | 4.5938 in |
| Seal type | Felt Seal |
| Overall length/diameter | 5.5625 in |
| Length through bore | 1.5625 in |
| Bore type | Round |
| Operating temperature range | Max 220° |
| Duty type | Standard Duty |
| Finish/coating | Uncoated |
| Mounting type | Two-Bolt Flange |
| Bolt size | 0.4375 in |
| Housing material | Cast Iron |
| Lubrication type | Lubrication Fitting |
| Locking device | Skwezloc Collar |
| Series | SFT-T |
| Expansion type | Non-Expansion Bearing (Fixed) |
| Replacement bearing | 1-14T |
| Housing width | 1.1719 in |
| Manufacturer catalog number | 714718 |
| Overall width | 3.25 in |
| Cad drawing | https://www.3dcontentcentral.com/PremiumSSS-Download-Model.aspx?catalogId=12261&id=1469 |
| Inner ring width | 1.5625 in |
