On request
SEALMASTER
Call
SEALMASTER CRFTS-PN32
#CRFTS-PN32
On request
711156
Manufacturer description711156 Flange-Mount Ball Bearing Unit - Two-Bolt Flange, 2.0000 in Bore, Stainless Steel Housing, Standard Duty, Set Screw Locking, High Performance Seal
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
SEALMASTER — SEALMASTER CRFTS-PN32
- With Seal Flinger
- GoldPlex-HP Grease
Specifications
| Brand | SEALMASTER |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 2 in |
| Bearing material | 52100 Steel/Black Oxide |
| Bolt center-to-center length | 7.25 in |
| Seal type | High Performance Seal |
| Overall length/diameter | 8.5 in |
| Length through bore | 2.1875 in |
| Bore type | Round |
| Operating temperature range | Max 220° |
| Duty type | Standard Duty |
| Finish/coating | Uncoated |
| Mounting type | Two-Bolt Flange |
| Bolt size | 0.625 in |
| Housing material | Stainless Steel |
| Lubrication type | Lubrication Fitting |
| Locking device | Set Screw |
| Series | CRFTS-PN |
| Expansion type | Non-Expansion Bearing (Fixed) |
| Replacement bearing | PN-32 |
| Housing width | 1.75 in |
| Manufacturer catalog number | 711156 |
| Overall width | 5.25 in |
| Cad drawing | https://www.3dcontentcentral.com/PremiumSSS-Download-Model.aspx?catalogId=12261&id=1020510 |
| Inner ring width | 2.1875 in |
