On request
SEALMASTER
Call
SEALMASTER TFT-16
#TFT-16
On request
721412
Manufacturer descriptionFlange-Mount Ball Bearing Unit - Two-Bolt Flange, 1.0000 in Bore, Ductile Iron Housing, Standard Duty
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | SEALMASTER |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 1 in |
| Radial static load capacity | 1651 lb |
| Bolt center-to-center length | 3 in |
| Length through bore | 1-15/16 in |
| Overall length/diameter | 3.75 in |
| Operating temperature range | -20 to +200 °F |
| Bore type | Round |
| Finish/coating | Uncoated |
| Duty type | Standard Duty |
| Maximum rpm | 6350 RPM |
| Mounting type | Two-Bolt Flange |
| Lubrication type | Lubrication Fitting |
| Housing material | Ductile Iron |
| Series | TFT-T |
| Expansion type | Non-Expansion Bearing (Fixed) |
| Replacement bearing | 2-1TC |
| Radial dynamic load capacity | 2801 lb |
