On request
SEALMASTER
Call
SEALMASTER CRFTC-PN23
#CRFTC-PN23
On request
711131
Manufacturer description711131 Flange-Mount Ball Bearing Unit - Two-Bolt Flange, 1.4375 in Bore, Composite Housing, Standard Duty, Set Screw Locking, High Performance Seal
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
SEALMASTER — SEALMASTER CRFTC-PN23
- With Seal Flinger
- GoldPlex-HP Grease
Specifications
| Brand | SEALMASTER |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 1.4375 in |
| Bearing material | 52100 Steel/Black Oxide |
| Bolt center-to-center length | 5.125 in |
| Seal type | High Performance Seal |
| Overall length/diameter | 6.3281 in |
| Length through bore | 1.6875 in |
| Bore type | Round |
| Operating temperature range | Max 220° |
| Duty type | Standard Duty |
| Finish/coating | Uncoated |
| Mounting type | Two-Bolt Flange |
| Bolt size | 0.5 in |
| Housing material | Composite |
| Lubrication type | Lubrication Fitting |
| Locking device | Set Screw |
| Series | CRFTC |
| Expansion type | Non-Expansion Bearing (Fixed) |
| Replacement bearing | PN-23 |
| Housing width | 1.3438 in |
| Manufacturer catalog number | 711131 |
| Overall width | 3.7031 in |
| Cad drawing | https://www.3dcontentcentral.com/PremiumSSS-Download-Model.aspx?catalogId=12261&id=17639 |
| Inner ring width | 1.6875 in |
