SEALMASTER SFT-29
#SFT-29
On request
700557
Manufacturer description700557 Flange-Mount Ball Bearing Unit - Two-Bolt Flange, 1.8125 in Bore, Cast Iron Housing, Standard Duty, Set Screw Locking, Felt Seal
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
SEALMASTER — SEALMASTER SFT-29
- With Seal Flinger
- GoldPlex-HP Grease
Specifications
| Brand | SEALMASTER |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 1.8125 in |
| Bearing material | 52100 Steel/Black Oxide |
| Bolt center-to-center length | 6.1875 in |
| Seal type | Felt Seal |
| Overall length/diameter | 7.4375 in |
| Length through bore | 2.0313 in |
| Bore type | Round |
| Operating temperature range | Max 220° |
| Duty type | Standard Duty |
| Finish/coating | Uncoated |
| Mounting type | Two-Bolt Flange |
| Bolt size | 0.5625 in |
| Housing material | Cast Iron |
| Lubrication type | Lubrication Fitting |
| Locking device | Set Screw |
| Series | SFT |
| Expansion type | Non-Expansion Bearing (Fixed) |
| Replacement bearing | 2-113 |
| Housing width | 1.5625 in |
| Manufacturer catalog number | 700557 |
| Overall width | 4.5625 in |
| Cad drawing | https://www.3dcontentcentral.com/PremiumSSS-Download-Model.aspx?catalogId=12261&id=1508 |
| Inner ring width | 2.0313 in |
