SEALMASTER MSFT-28TC
#MSFT-28TC
On request
705729
Manufacturer description705729 Flange-Mount Ball Bearing Unit - Two-Bolt Flange, 1.7500 in Bore, Cast Iron Housing, Medium Duty, Skwezloc Collar Locking, Contact Seal
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
SEALMASTER — SEALMASTER MSFT-28TC
- Without Seal Flinger
- GoldPlex-HP Grease
Specifications
| Brand | SEALMASTER |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 1.75 in |
| Bearing material | 52100 Steel/Black Oxide |
| Bolt center-to-center length | 6.1875 in |
| Seal type | Contact Seal |
| Overall length/diameter | 7.4375 in |
| Length through bore | 2.0938 in |
| Bore type | Round |
| Operating temperature range | Max 220° |
| Duty type | Medium Duty |
| Finish/coating | Uncoated |
| Mounting type | Two-Bolt Flange |
| Bolt size | 0.5625 in |
| Housing material | Cast Iron |
| Lubrication type | Lubrication Fitting |
| Locking device | Skwezloc Collar |
| Series | MSFT |
| Expansion type | Non-Expansion Bearing (Fixed) |
| Replacement bearing | 3-112TC |
| Housing width | 1.5625 in |
| Manufacturer catalog number | 705729 |
| Overall width | 4.5625 in |
| Cad drawing | https://www.3dcontentcentral.com/PremiumSSS-Download-Model.aspx?catalogId=12261&id=11315 |
| Inner ring width | 2.0938 in |
