SEALMASTER MFC-48
#MFC-48
On request
701813
Manufacturer description701813 Piloted Flange-Mount Ball Bearing - Four-Bolt Flange, 3.0000 in Bore, Cast Iron Housing, Medium Duty, Set Screw Locking, Felt Seal
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
SEALMASTER — SEALMASTER MFC-48
- With Seal Flinger
- GoldPlex-HP Grease
Specifications
| Brand | SEALMASTER |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 3 in |
| Seal type | Felt Seal |
| Bolt circle diameter | 7.5 in |
| Operating temperature range | 250° |
| Overall length/diameter | 8.75 in |
| Finish/coating | Uncoated |
| Bore type | Round |
| Pilot diameter | 6.375 in |
| Duty type | Medium Duty |
| Bolt size | 0.625 in |
| Mounting type | Four-Bolt Flange |
| Lubrication type | Lubrication Fitting |
| Housing material | Cast Iron |
| Series | MFC |
| Locking device | Set Screw |
| Replacement bearing | 43527 |
| Expansion type | Non-Expansion Bearing (Fixed) |
| Manufacturer catalog number | 701813 |
| Housing width | 2.4063 in |
| Cad drawing | https://www.3dcontentcentral.com/PremiumSSS-Download-Model.aspx?catalogId=12261&id=3263 |
| Inner ring width | 3.25 in |
| Manufacturer upc number | 662461013489 |
