On request
SEALMASTER
Call
SEALMASTER FB-23
#FB-23
On request
701245
Manufacturer description701245 Flange-Mount Ball Bearing Unit - Three-Bolt Flange, 1.4375 in Bore, Cast Iron Housing, Standard Duty, Set Screw Locking, Felt Seal
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
SEALMASTER — SEALMASTER FB-23
- With Seal Flinger
- GoldPlex-HP Grease
Specifications
| Brand | SEALMASTER |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 1.4375 in |
| Bearing material | 52100 Steel/Black Oxide |
| Bolt center-to-center length | 2 in |
| Seal type | Felt Seal |
| Overall length/diameter | 6.125 in |
| Length through bore | 1.6875 in |
| Bore type | Round |
| Operating temperature range | Max 220° |
| Duty type | Standard Duty |
| Finish/coating | Uncoated |
| Mounting type | Three-Bolt Flange |
| Lubrication type | Lubrication Fitting |
| Housing material | Cast Iron |
| Series | FB |
| Locking device | Set Screw |
| Replacement bearing | 43513 |
| Expansion type | Non-Expansion Bearing (Fixed) |
| Manufacturer catalog number | 701245 |
| Housing width | 1.4688 in |
| Cad drawing | https://www.3dcontentcentral.com/PremiumSSS-Download-Model.aspx?catalogId=12261&id=3104 |
| Overall width | 1.875 in |
| Manufacturer upc number | 662461010242 |
| Inner ring width | 1.6875 in |
