On request
SEALMASTER
Call
SEALMASTER FB-204
#FB-204
On request
710123
Manufacturer description710123 Flange-Mount Ball Bearing Unit - Three-Bolt Flange, 20 mm Bore, Cast Iron Housing, Standard Duty, Set Screw Locking, Felt Seal
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
SEALMASTER — SEALMASTER FB-204
- With Seal Flinger
- GoldPlex-HP Grease
Specifications
| Brand | SEALMASTER |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 20 mm |
| Inner ring width | 31 mm |
| Bolt center-to-center length | 38.1 mm |
| Bearing material | 52100 Steel/Black Oxide |
| Overall length/diameter | 106.4 mm |
| Seal type | Felt Seal |
| Bore type | Round |
| Length through bore | 31 mm |
| Duty type | Standard Duty |
| Operating temperature range | Max 220° |
| Mounting type | Three-Bolt Flange |
| Finish/coating | Uncoated |
| Housing material | Cast Iron |
| Lubrication type | Lubrication Fitting |
| Locking device | Set Screw |
| Series | FB |
| Expansion type | Non-Expansion Bearing (Fixed) |
| Replacement bearing | 5204 |
| Housing width | 25.4 mm |
| Manufacturer catalog number | 710123 |
| Overall width | 34.1 mm |
| Cad drawing | https://www.3dcontentcentral.com/PremiumSSS-Download-Model.aspx?catalogId=12261&id=3090 |
