SEALMASTER
Call
SEALMASTER NPL-36C
#NPL-36C
On request
703577
Manufacturer description703577 Ball Bearing Low Base Unit - Two-Bolt Base, 2.2500 in Bore, Cast Iron Material, Normal Duty, Non-Expansion Bearing (Fixed)
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
SEALMASTER — SEALMASTER NPL-36C
- Without Seal Flinger
- GoldPlex-HP Grease
Specifications
| Brand | SEALMASTER |
| Category | PILLOW BLOCK BALL BEARING UNITS |
| Mounting | Two-Bolt Base |
| Finish/coating | Uncoated |
| Bore diameter | 2.25 in |
| Overall width | 2.5625 in |
| Bore type | Round |
| Operating temperature range | Max 250° |
| Base to bore centerline | 2.6875 in |
| Base width | 2.75 in |
| Duty type | Normal Duty |
| Bolt center-to-center length | 6.8750 to 7.6250 in |
| Housing material | Cast Iron |
| Bolt size | 0.625 in |
| Locking device | Set Screw |
| Lubrication type | Lubrication Fitting |
| Seal type | Contact/Lip |
| Series | NPL |
| Expansion type | Non-Expansion Bearing (Fixed) |
| Replacement bearing | 2-24C |
| Overall length | 9.5 in |
| Manufacturer catalog number | 703577 |
| Overall height | 5.5 in |
| Cad drawing | https://www.3dcontentcentral.com/PremiumSSS-Download-Model.aspx?catalogId=12261&id=10905 |
