SKF QJ330N2MA

Name: SKF QJ330N2MA
Brand: SKF
SKU: QJ330N2MA

#QJ330N2MA On request

Brand SKF

Category FOUR-POINT CONTACT BEARINGS

Part Number QJ330N2MA

QJ 330 N2MA

Manufacturer description

QJ Series Four-Point Angular Contact Bearing - 150 mm Bore, 320 mm OD, 65 mm Width, Open

Price on request — a consultant will confirm lead time and terms.

Talk to a technical consultant

Specifications

Brand	SKF
Category	FOUR-POINT CONTACT BEARINGS
Inside diameter	150 mm
Bearing material	Steel
Outside diameter	320 mm
Cage material	Brass
Overall width	65 mm
Maximum rpm	3600 rpm
Contact angle	35 °
Finish/coating	Uncoated
Closure type	Open
Series	QJ
Maximum operating temperature	257 °
Manufacturer product page	http://www.skf.com/us/products/bearings-units-housings/ball-bearings/angular-contact-ball-bearings/four-point-contact-ball-bearings/four-point-contact-ball-bearings/index.html?designation=QJ%20330%20N2MA
Radial dynamic load capacity	530 kN
Manufacturer upc number	7316577035493
Radial static load capacity	765 kN
Weight	63.9 lbs
