SKF SYJ80TF
#SYJ80TF
On request
SYJ 80 TF
Manufacturer descriptionPillow Block Ball Bearing Unit - Two-Bolt Base, 80 mm Bore, Cast Iron Material, Non-Expansion Bearing (Fixed)
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | SKF |
| Category | PILLOW BLOCK BALL BEARING UNITS |
| Mounting | Two-Bolt Base |
| Overall width | 3-1/16 in |
| Bore diameter | 80 mm |
| Radial dynamic load capacity | 72.8 kN |
| Bore type | Round |
| Radial static load capacity | 53 kN |
| Base to bore centerline | 3.5 in |
| Base width | 78 mm |
| Housing material | Cast Iron |
| Bolt center-to-center length | 232 mm |
| Locking device | Set Screw |
| Maximum rpm | 2400 RPM |
| Expansion type | Non-Expansion Bearing (Fixed) |
| Lubrication type | Lubrication Fitting |
| Overall length | 292 mm |
| Series | SYJ |
| Overall height | 176 mm |
| Replacement bearing | YAR 216-2F |
| Finish/coating | Uncoated |
| Standards met | ISO |
