SMC VQ4100-5W-Q
#VQ4100-5W-Q
On request
VQ4100-5W-Q VALVE
Manufacturer descriptionSolenoid-Operated Air Control Valve - Base Mounted, 5 Port, 2 Position, Single Solenoid, Subplate Not Included
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | SMC |
| Category | SOLENOID-OPERATED AIR CONTROL VALVES |
| Number of ports | 5 |
| Maximum operating pressure | 101 psi |
| Piping type | Base Mounted |
| Seal material | Metal |
| Number of positions | 2 |
| Operating medium | Air, Inert Gas |
| Number of solenoids | Single |
| Flow direction | 4-Way |
| Solenoid supply voltage | 24 V dc |
| Subplate port size | 3/8 BSPT |
| Flow coefficient (cv) / flow factor (kv) | 1.5 (P to A/B) , 1.7 (A/B to EA/EB) Cv |
| Port size | Subplate Mounted |
| Manual operation type | Non-Locking Push |
| Standards met | JIS B 8375-1981 |
| Operating temperature range | 14 to 122 °F |
