SMC KQ2K06-U02
#KQ2K06-U02
On request
KQK06-U02
Manufacturer descriptionSMC® KQ2K06-U02 Push-In to Metric Threaded Pneumatic Tubing Fitting, Connection 1 Short Name: Push-In, Hex Size: 14mm
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | SMC |
| Category | PUSH-TO-CONNECT TUBE FITTINGS |
| Fitting shape | 45° Elbow |
| Flow control type | None |
| Compatible tube outer diameter | 6 mm |
| Hex size | 14 mm |
| Operating temperature range | -5 to +60 (No Freezing) , 0 to +40 (Water) °C |
| Overall diameter | 12.8 mm |
| Body material | PBT, C3604 |
| Overall length | 31 mm |
| Operating pressure range | -100 to +1 kPa, MPa |
| Fitting connection family | Push-In to Uni |
| Number of ports | 2 |
| Fitting connection type | 6 Female Push-In to 1/4 Male Uni Threaded |
| Burst pressure | 3 Mpa |
| Maximum operating pressure | +1 Mpa2 |
