TB WOODS (ALTRA) QTMPB
#QTMPB
On request
QTX7/16" MPB BUSHING
Manufacturer descriptionQuick Disconnect Bushing - QT Bushing, 0.4375 in Bore, 2.5000 in Flg OD, 1.2500 in LTB
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
TB WOODS (ALTRA) — TB WOODS (ALTRA) QTMPB
- Six-hole drilling (most sizes) makes installation and removal quick and easy
- Precise taper (3/4" per-ft on dia) provides proper wedging action
- Versatile Sure-Grip bushings permit the mounting of the same mating part on shafts of different diameters, and the mounting of different sheaves on the same shaft using the same bushing
Specifications
| Brand | TB WOODS (ALTRA) |
| Category | QD BUSHINGS |
| Bore diameter | 0.4375 in |
| Mounting type | Conventional or Reverse |
| Flange outside diameter | 2.5 in |
| Screw torque | 9 ft-lbs |
| Flange thickness | 0.25 in |
| Barrel diameter | 1-5/8 in |
| Length through bore | 1.25 in |
| Barrel length | 1 in |
| Bushing size | QT |
| Bolt circle diameter | 2 in |
| Bore type | Finished w/ No Keyway |
| Number of bolt holes | 2 |
| Keyway size | No Keyway |
| Screw thread size | 1/4-20 in |
| Torque capacity | 1750 in-lbs |
| Screw length | 1 in |
