TIMKEN (FAFNIR) VFTDR1
#VFTDR1
On request
Flange-Mount Ball Bearing Unit - Two-Bolt Flange, 1.0000 in Bore, Cast Iron Housing, Eccentric Collar Locking, Contact Seal
Price on request — a consultant will confirm lead time and terms.
Need to confirm compatibility?
Talk to a technical consultant
Specifications
| Brand | TIMKEN (FAFNIR) |
| Category | FLANGE-MOUNT BALL BEARING UNITS |
| Bore diameter | 1 in |
| Seal type | Contact Seal |
| Bolt center-to-center length | 3 in |
| Length through bore | 27/32 in |
| Overall length/diameter | 3.75 in |
| Finish/coating | Uncoated |
| Bore type | Round |
| Maximum rpm | 5440 RPM |
| Mounting type | Two-Bolt Flange |
| Lubrication type | Lubrication Fitting |
| Housing material | Cast Iron |
| Series | VFTDR |
| Locking device | Eccentric Collar |
| Standards met | FDA Compliant, USDA Compliant |
| Expansion type | Non-Expansion Bearing (Fixed) |
| Replacement bearing | RA100RRB |
| Radial dynamic load capacity | 3550 lb |
| Radial static load capacity | 1730 lb |
